L298N Motor Shield DC motor drives using ST STMicroelectronics excellent dedicated high-power motor driver chip L298N direct drive DC motors two-phase four-phase stepper motor drive current up to 2A motor output using eight high-speed Schott Schottky diodes for protection. The circuit reasonable wiring laminated design can be directly plugged into the for Arduino to use user-friendly and reduces the technical difficulty of the drive motor.
In this book a phase-difference angle (PDA) controlled pulse width-modulated (PWM) inverter instead of phase voltage modulation and/or frequency changing is proposed to control the speed, and position of a two-phase induction motor. Several characteristics of a two–phase induction motor driven by the PDA inverter are studied to verify the improvement of the motor performances. Also, speed, and position tracking are achieved using the proposed control technique. The book covers in more details the main principles characteristics of the two-phase induction motor especially at voltage, frequency, PDA changing. The difference among them is studied carefully to conclude the best control method. For unbalanced operation of the two-phase induction motor when used either as a servomotor or single-phase applications. The method of symmetrical components transformation is used to simplify the steady state analysis of the machine.. An experimental prototype, which consists of a PC computer based controller, a PDA inverter, and two phase induction motor is used to verify the validity of the proposed control technique .
Brand NO Model NO Quantity 1 Color Blue Material FR4 Features DC motor speed measurement can also do PWM Specification Photoelectric unit: ITR9608 Voltage: 3~6V; Output signal: impulse wave; Control signal: Digital level; 0 or 1;Speed control signal: PWM mode Application Learn the principle of motor speed control English Manual/Spec Yes Packing List 1 x DC motor drive module
Brand N/A Model 015 Quantity 1 Color White + silver Material FR4 Features Compatible with Arduino Pulse Width Modulation speed control model 4 direction indicator light; Compatible with linker; 2.54mm space plug and play sensor module; Additional large radiator Specification The is motor module is perfect for robot and mechanical use; It makes the Arduino with 2 brushless DC motor and stepping motor 2 phase 4 wires; Base on L298N chip constant-speed drive motor to drive integrated circuit it needs 6~15V power to drive the motor and including car 5V voltage regulator use to drive Arduino PCB; Plug and play 2.54mm space Grove sensor can connect to 13 car Grove connector; Logic Control Voltage: Min: 4.5V Typical: 5V Max:5.5V; Motor Supply Voltage: Min: 6V Max: 15V Output Voltage: Min:0 Max: input: 1 V Output Current( For Each Channel): Max: 2000mA Output Duty range: 0%~100%; Please refer to http://linksprite.com/wiki/index.php5?title=Motor_Shield Application Robot and mechanical use English Manual/Spec No Other A product for Arduino that works with official Arduino boards. Packing List 1 x Motor module
This work focuses on the performance analysis of a reduced switch three phase Z-source inverter fed cost effective induction motor drive system. In the proposed approach, instead of a conventional six switch three phase inverter a four switch three phase Z-source inverter is utilized. This reduces the cost of the inverter, the switching losses, and the complexity of the control algorithms. The new Z-source inverter system provides ride-through capability during voltage sags, reduces line harmonics, improves power factor, reliability and extends output voltage range. Validations of the theory and reduction methods are performed experimentally. This proposed method is able to reduce conduction noise in contrast with the existing conventional inverters. Analysis, simulation and experimental results are presented to demonstrate these new features.
IRF520 driver module: Voltage: 3.3V / 5V; Interface: digital level; Output load voltage: 0~24V; Output load current: <5A (need heatsink when current beyond 1A); Suitable for Arduino SCM ARM and Raspberry Pi Features: Adopts IRF520 MOS transistor support PWM output; Arduino can drive 24V load such as LED light strip DC motor micro pump and solenoid valve; Can achieve LED stepless dimming variable speed motor through PWM DC motor: low working current; Wide voltage: 2.5~12V; Each channel has 800mA continuous current output capability; Compatible w/ TTL / CMOS output level can connect to CPU directly; Built-in lead diode on output suitable for inductive load to control and drive IC
Uses ST' L298N chip can directly drive two 3-30V DC motor and provide a 5V output interface power for 5V single-chip circuitry support 3.3VMCU control - Can easily control the DC motor speed and direction also control the 2-phase stepper motor - Driver: L298N Dual H Bridge DC Motor Driver IC - Driven part of the terminal supply voltage: VMS 5~35V - Driven part of the peak current Io: 2A per bridge - The logical part of the terminal supply voltage: 4.5~7V - The logical part of the operating current range: 0 ~ 36mA - Control signal input voltage range: 4.5~5.5V (high) / 0V (low) - Maximum power consumption: 20W
On-board two L9110S motor control chip; Can drive two DC motor or one 4-wire 2-phase stepper motor at the same time; Input voltage: 2.5~12V; Each channel has 800mA current output.
Reversing motor control with LED indication; Can drive a stepper motor; Photoelectric sensor measuring motor speed
Model: HG7881 - Quantity: 1 - Material: PCB + plastic + iron - Color: Blue + green + black - On-board two the HG7881 motor control chip - The module can simultaneously drive two DC motor or a 4-wire 2-phase stepping motor - Input voltage :2.5~12V - Each channel has a 800mA continuous current output capacity - English Manual/Spec: Yes - Great for DIY project. - Packing list: - 1 x Motor drive board
Model: ULN2803 - Quantity: 1 - Color: Red - Material: PCB board - ULN2803 stepper can control 2 4-phase stepper motor. - There are ten pins in the left 8 pins supply 5-volt power input and leads to an external power supply and the right side for the two stepper motor output connected to two 4-phase five-wire stepper motor. drive capability 500MA \ 50V. Can be a direct replacement for the ULN2003 to drive the four-phase wireless stepper motor. - Working voltage: DC +5V - Great for DIY project
A PM Brushless DC motor drive system is used to control the speed or the position of a Permanent Magnet Brushless DC motor. The position and speed sensors have some disadvantages such as increasing cost and reducing the drive robustness. By the reason, sensorless control has been studied for the last decades but the study has been still reminding problems. Therefore, a novel estimation technique for speed and position of PMBLDC motor is proposed. In the technique, the speed and position is calculated from estimated back-EMF which is estimated by only measurable voltages and currents of the PMBLDC motor. This book indicated following that Analysis of PMBLDC motor, Review of estimation method in previous research in PMBLDC motor, Modeling and simulation and analysis in Matlab/Simulink, Implementing estimation method with LabVIEW.
Brand Jtron Model 03100438 Quantity 1 Color Green Material Glass fiber + plastic + iron Specification Input voltage is DC9-32V the maximum output current of 2.2A Features Designed for micro-stepping motors Application For your DIY project English Manual/Spec Yes Other Product description: 1. Stepper motor driver designed for micro stepping motor can drive 24283942etc 2.2A current hybrid two-phase stepping motor has a very high price. This section also can drive 57 motors but is not recommended with 57 motor work for a long time if need the motor 57 you can use the TB6560 drive or THB7128 drive. The stepping motor driver has the following features: support the whole step 2 4 8 16 32 64 128 a total of 8 kinds of subdivision. 2. The maximum output current is 2.2A can be matched with various 2A within the 2 phase of small step motor current 0.2-2A stepless adjustable arbitrarily set. Potentiometer is stepless current scale marks are for reference. If your machine is the intermediate can be 0.5A to 0.4A and 0.6A scale 3. Input voltage for the DC9-32V. is equipped with a power indicator. 4. Input circuit with anti power reverse design more safety. 5. Automatic flow on / off function work more like. Set to switch M4. 6. Attenuation mode control function. In the matching of different types of stepper motor control can work in different ways so that the operation of the motor is more stable noise vibration control to a minimum. Set as close to the LED indicating lamp position potentiometer. The matching of the motor adjust the potentiometer the vibration and noise to a minimum to motor. 7. Industry-standard input and output interfacesstrong compatibility can support a total of yin or Yang connection. Equipped with a large radiator the screw and the fixed column more convenient to use. Terminal description: The signal input: 1. PUL+/CLK+: pulse signal input positive terminal 2. PUL-/CLK-: pulse signal input negative terminal. 3. DIR+/CWW+: Motor forward and reverse control positive terminal 4. DIR/-CWW-: Motor forward and reverse control negative terminal 5. EN (A) /FREE+: Motor offline control the positive terminal. 6. EN (A) /FREE-: Motor offline control negative end. The motor winding connection: 1.A+/OUT1A: connecting the motor winding A. 2.A-/OUT2A: connecting the motor winding A- 3.B+/OUT1B: connecting the motor winding B 4.B-/OUT2B: connecting the motor winding B-. Special note: don't (1) (3) or (2) (4) cross connected to the motor line will burn drive. When debugging the best connected motor line measured with a multimeter drive terminals: A+ A- is the same B+ B- is the same. A+ and B+ are not connected so as to power on test machine. Connected with the working voltage: 1. V+/VM :Connect the DC positive power 2.V-/GND: Connect the DC negative power Matters needing attention: 1.Drive power capacity of at least match should have more than 2.Otherwise unstable work. 2. Motor lines cannot cross the AB line or burning drive. 3. When using PLC to add on about 2K current limiting resistor or burning drive. Packing List 1 x Stepper Motor Drive
